GPS RTK Acnovo Gx 10

Rp150,000,000 Rp90,000,000

Kelengkapan Penjualan :

  • Base
  • Rover
  • Controller
  • Radio Eksternal
  • Tripod/Statif
  • Tribrach
  • Pole

Note:
*Harga Dapat Berubah Sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
*Mohon tanya ketersediaan barang terlebih dahulu.
*Barang selalu kami cek terlebih dahulu sebelum di kirim.
*Barang di toko kami di jamin original dan baru

Categories: , , ,

Description

GPS RTK Acnovo Gx 10

Surveying Performance
Signal tracking :
336 channel,  BDS: B1B2B3, GPS:  L1C/A, L1C, L2C, L2E, L5,
GLONASS: L1C/A, L1P, L2C/A, L2P, L3, SBAS: L1C/A, L5
Galileo GIOVE-A and GIOVE-B, E1, E5A, E5B
QZSS, WAAS, MSAS, EGNOS, GAGAN (SBAS)
GNSS Features
Positioning output rate: 1Hz~50Hz, Initialization time: <10s,
Initialization reliability: >99.99%
Positioning precision
Code differential GNSS positioning :
Horizontal ±0.25m + 1ppm
Vertical ±0.50m + 1ppm
SBAS positioning accuracy: typically<5m 3DRMS
Static GNSS surveying : ±(2.5mm + 0.5mm/km × d) (d: the distance between measured points, km)
Real-time kinematic surveying : ±(10mm + 1mm/km × d) (d: the distance between measured points, km)
Operation system/User interface
OS : Linux
Button : Double buttons and visual operation interface
LCD : Double buttons and visual operation interface
Web interaction : Visiting the internal management web page via WIFI or USB mode, to monitor the receiver, status and change the configuration freely.
Voice: iVoice intelligent voice technology provides status and operation voice promptly, Supporting Chinese, English, Korean, Russian, Portuguese, Spanish, Turkish, Supporting user defined voice.
Secondary development : Providing secondary development package, and opening the OpenSIC observation data, format and interface definition for secondary developmen
Data cloud service
Web page cloud service management platform, supporting online register etc
Hardware performance
Dimension : 142mm (diameter) × 137mm(height)
Weight : 1.1kg (including battery)
Material: Magnesium alloy shell
Temperature: Operating: -45°C ~ +65°C, Storage: -55°C ~ +85°C
Humidity:  100% Non-condensing
Protection Level:  Waterproof: IP68 standard, protected from long time immersion to depth of 1m, Dustproof: IP68 standard, fully protected against blowing dust.
Shock and vibration: Withstand 3 meters drop onto the cement ground naturally
Electrical:  9-25v wide voltage DC design, with overvoltage protection
Battery: High capacity removable battery with the indicator displaying the power usage, Voltage 11.1v, 37.7Wh
Battery Life: More than 30h (static mode), More than 15h (RTK mode), (Providing the 7 × 24h battery solution)
Communications
I/O port: 5PIN LEMO external power port + Rs232, 7PIN LEMO external USB (OTG), 1 network/radio data link antenna port, SIM card slot
Wireless modem: Integrated internal radio receiver and transmitter 1W/2W, External radio transmitter 5W/35W (Optional),  Working frequency 410-470MHz, Communication protocol: TrimTalk450s, SOUTH
Cellular mobile network: WCDMA3.5G network communication module, GPRS/EDGE compatible, CDMA2000/EVDO 3G and TDD-LTE, FDD-LTE 4G optional CDMA2000/EVDO 3G and TDD-LTE, FDD-LTE 4G optional.
Double module Bluetooth: BLEBluetooth 4.0 standard, support for android, ios cellphone connection, Bluetooth 2.1 + EDR standard
WIFI
WIFI hot spot: Adopting the WIFI hot spot function, any smart terminals (controller, cellphone and PC) can connect to the receiver easily
WIFI data link: The receiver can transmit and receive correction via WiFi
Data storage/ transmission
Data storage: 4GB internal storage, Supporting external USB data storage, Changeable record interval, supports up to 50Hz raw data collection
Data transmission: USB data transmission, FTP download, HTTP download
Data format: Static data format: DAT, Rinex2.x and Rinex3.x etc.
Differential data format: CMR+, CMRx, RTCM 2.1, RTCM 2.3, RTCM 3.0, RTCM 3.1, RTCM 3.2, output data format: NMEA 0183ã€ÂPJK plane coordinatesã€Âbinary codeã€ÂTrimble GSOF
Network model support: VRS, FKP, MAC, supporting NTRIP protocol
Inertial sensing system
Tilt survey: Built-in tilt compensator, correcting coordinates automatically according to the tilt direction and angle of the centering rod
Electronic bubble: Controller software display electronic bubble, checking leveling status of the centering rod real time
Thermometer: Built-in thermometer sensors, adopting intelligent temperature control technology, monitoring and adjusting the receiver temperature in real time .
Controller:
System:
OS: Android 5.1
CPU : 1.5GHzx4 Cortex A53 Quad Core 64 bits
Internal memory : 3GB RAM, 32 G ROM
Extended Memory: 64 G Maximum, T-Flash Card
Multimedia
Integration : Speaker, Microphone,Compas, G-Sensor, OTG
Camera : 13 Megapixel
Screen : 540×960 resolution, 4.5 inch touch screen
Communication
Interface : Micro-USB interface (Support charge power)
OTG Interface, ear phone interface
2G/3/G/4G : GSM (B2/3/5/), WCDMA(B1/2/5/8), TDCDMA(B34/39), TD-LTE
Bluetooth : Bluetooth V4.0 (A2DP+EDR)
WiFi : 802.11a/b/g/ (2.5G/5G Dual Frequency)
Power
Battery : 1 pcs, removable 5000mAH Lithium Battery
Work Time : More than 10 hours / one battery
Envoronment
Operattion temperature : -20°C – +60°C
Storage Temperature : -40°C – +80°C
Dust/Water Proof : IP65
Pysical
Dimension : 197x92x26.5 (mm)
Weight : 380 with battery
Configuration:
2x Receiver, 1x Controller, 4x Battery, 2x Charger,
1x Tripod, 1x Carbon Pole, 1x Bracket

Additional information

Weight 35 kg
