Hi-Target V30
free
Bipod dan pole
tripod Statif

include total 2box :
-contoller i hand 20 1
– pole mini 1
– antena 2
– baterry BL-500 4
– charger cl4400 2
– kabel data 1
– kabel aki 1
– holding controller 1
– meteran 1
– baterai BLP 36005 1

Bergaransi dan banyak bonus lainya

GPS RTK BUAT PTSL, GCP, TOPOGRAPI

bisa di gunakan untuk Statik/Geodetik



Dapatkan Harga Khusus Untuk yang Datang ke Offline Store.

alat RTK HEMISPHIRE Hanya di rentalkan saja Perbulan 25JT



SPESIFICATION GPS SOUTH RTK S86T

Field Genius
·Built-in Transmitting Radio Module
·Built-in GPRS/GSM Module
·Open Port for External Radio Access

Features :
* Built-in Transmitting Radio Module
The mini 0.5W radio transmitter equipped inside is a distinct feature that brings you great convenience. Within effective working range (3-5km typical, 8-10km optimal), you may switch freely between base station and rover, therefore complicated base setup and displacing the external radio transmitter as well as the external power supply are no longer necessary to you.

* Built-in GPRS/GSM Module
Such a module has enabled this receiver to be multifunctional, which helps you easily change between radio RTK mode and network RTK mode subject to the practical condition. Interchangeability would definitely get you a very economical solution.

* Open Port for External Radio Access
S86T is connectible with external radio transmitters at different power rates for longer working range (8-10km typical, 15-20km optimal). The multiple choices allow you more options for radio access.

Receiver Part
Measurements

General Info
220 channels, by advanced Pacific Crest Maxwell 6 Custom Survey GNSS technology
High precision multiple correlator for GNSS pseudo range measurements
Unfiltered, unsmoothed pseudo range measurements data for low noise, low multipath error, low time domain correlation and high dynamic response Very low noise GNSS carrier phase measurements with 1mm precision in a 1Hz bandwidth
Signal-to-Noise ratios reported in dB-Hz Proven Pacific Crest low elevation tracking technology

Satellite signals tracked simultaneously
– GPS: L1 C/A, L2E, L2C, L5 (reserved)
– GLONASS: L1 C/A, L1 P, L2C/A (GLONASS M only), L2 P
– SBAS: L1 C/A, L5 (reserved)
– Galileo: (reserved)
supports GIOVE-A: L1BOC, E5A, E5B, E5AltBOC
supports GIOVE-B: L1CBOC, E5A, E5B, E5AltBOC
– Compass: (reserved)
B1 (QPSK), B1-MBOC (6,1,1/11), B1-2 (QPSK)
B2 (QPSK), B2-BOC (10, 5),
B3 (QPSK), B3BOC (15, 2.5)
L5 (QPSK)

Code differential GNSS positioning
Horizontal: 25cm+1ppm RMS
Vertical: 50cm+1ppm RMS
SBAS differential positioning accuracy: typically <5m
3DRMS

Static and FastStatic GNSS surveying
Horizontal: 3mm+0.5ppm RMS
Vertical: 5mm+0.5ppm RMS

Realtime Kinematic surveying
Horizontal: 8mm+1ppm RMS
Vertical: 15mm+1ppm RMS
Initialization time: typically <8s
Initialization reliability: typically >99.9%

Hardware
Physical

Dimension (L x W x H): 158mm x 158mm x 78mm (6.2in z 6.2in x 3.1in)
Weight: 1.35kg (2.98lb) with battery and radio built in

Temperature
Operating: -40℃ ~ +65℃ (-49F ~ +140F)
Storage: -55℃ ~ +85℃ (-67F ~ +185F)
Humidity: 100%, condensing
Water/Dustproof: tested to IP67 standard, protected from temporary immersion to depth of 1m (3.28ft)
Shock and vibration: Designed to survive a 2m (6.6ft) pole drop onto concrete

Electrical
Power 12-15V DC external power input
Rechargeable, 7.4V, 10000mAh Lithium-Ion battery units built in receiver
Battery life: 15-20 hours for built-in battery (varies with temperature and working mode)

Communications and Data Storage
Standard USB2.0 port
RS-232 port: Baud rates up to 115200
Fully sealed and integrated 2.4GHz communication Bluetooth port
UHF receiving antenna port
Fully sealed and integrated 450-470MHz receiver
Built-in GDL2 Radio (Default configuration)
– Transmit power: 0.5W
– UHF Range (varies with terrain / temperature): 3-5km typical/8-10km optimal
Standard GDL20 (Optional)
– Transmit power: 25W
– UHF Range (varies with terrain / temperature): 8-10 km typical/15-20 km optimal
Mini GDL5 Radio (Optional)
– Transmit power: 2/5W
– UHF Range (varies with terrain / temperature): 3-5km typical/8-10km optimal
Fully sealed and integrated internal GPRS/GSM module
External cellphone support for GPRS/GSM module for network RTK (CORS) operations
Network RTK (via CORS) range (varies with temperature / GPRS data rate): 20-50km
Data storage: internal memory 4GB
Recording Rate: 1Hz positioning, up to 20Hz (supported by mainboard Bd970)
Reference outputs: CMR+, CMR+, RTCM 2.1, RTCM 2.2, RTCM 2.3, RTCM 3.0, RTCM 3.1

Remarks
Measurement accuracy and operation range might vary due to atmospheric conditions, signal multipath, obstructions, observation time, temperature, signal geometry and number of tracked satellites.
Specifications subject to change without prior notice.

Controller Part
Platform
– PXA270 624 MHz processor
– 1 GB Flash ROM
– 256 MB RAM

Operating System
– Windows CE 5 (standard supply)
– Windows Mobile 6 Classic, Professional (optional)

Wireless Communications
– Integrated Bluetooth?Class II, V 2.0 + EDR

External Connectors
– One tether connection with full RS232 and USB On-The-Go (USB 1.1) functionality
– One Low-Insertion Force (LIF) docking connector
– DC Power Jack

User Interface
– Color screen / Touch display
– 3.7 in (9.398 cm)
– Full VGA 480 x 640 Resolution
– Transflective, portrait mode TFT
– Sunlight readable (for outdoor use)
– High-reliability adjustable LED
– Backlight featuring a bright
– 165 cd/m2 output
– Touchscreen (standard)
– Passive stylus or finger operation
– Signature capture
– Full Alphanumeric keyboard
– Backlit, high durability hard-capped keys

Expansion Slots
– One SD/MMC memory card slot
– End-cap USB Interface supports GPS expansion module.
– 100-PIN expansion interface: supports PCMCIA (type II), GPRS/EDGE and otherthird-party expansion modules developed using Psion Hardware Developer’s Kit.
– One Type II CF Card Slot

Power Management
– Optional 3.7V, 2700 mAh standard capacity battery
– Advanced smart battery with gauge
– Built in charger
– Rechargeable, user replaceable backup battery pack

Environmental
– Withstands multiple drops from 6 ft (1.8 m) or 26 drops (on 12 edges, 6 corners, 8 faces) from 5 ft (1.5 m) to concrete while powered on
– Waterproof/Dustproof: IP65, IEC 60529
– Operating temperature: degrees Fahrenheit (-4 F) to degrees Fahrenheit (122 F) (-20centigrade to +50centigrade)
– 5%-95% RH non-condensing
– Storage temperature: degrees Fahrenheit (-40 F) to degrees Fahrenheit (140 F) (-40centigrade to +60centigrade)
– ESD: +/- 8kVdc air discharge, +/-4kVdc contacts

Physical
– Dimension(LxWxH): 223x100x42mm (8.78×3.94×1.65in)
– Weight: 0.46kg (1 lb) without battery

HUBUNGI CONTACT PERSON UNTUK HARGA & KETERSEDIAAN STOK
